Upload AVGS Data to IDE

---
title: SysML Activity Diagram - Upload AVGS Data to IDE
---
flowchart TD
    Start(((Start))) --> U1[Receive Processed AVGS Results Package]
    U1 --> U2[Authenticate to Integrated Data Environment IDE]
    U2 --> U3{Authentication OK?}
    U3 -->|No| U3a[Log Failure / Alert Operator] --> EndErr(((End - Error)))
    U3 -->|Yes| U4[Classify Results by Destination Domain]

    U4 --> FK{{Fork - Parallel Uploads}}

    FK --> D1[Upload MFOQA Events to Safety / Training Repo]
    FK --> D2[Upload CBM+ Analytics to Predictive Maint. Repo]
    FK --> D3[Upload Integrity / Fatigue Data to ASIP Repo]
    FK --> D4[Upload Work Orders to Maintenance Mgmt System]
    FK --> D5[Upload ILS Updates to Logistics System]
    FK --> D6[Upload Tech Pubs Feedback / TCTOs]
    FK --> D7[Upload Readiness Metrics to Fleet Dashboard]
    FK --> D8[Upload Raw + Processed Data to Engineering Data Lake / PLM Digital Thread]

    D1 --> JN{{Join}}
    D2 --> JN
    D3 --> JN
    D4 --> JN
    D5 --> JN
    D6 --> JN
    D7 --> JN
    D8 --> JN

    JN --> V1[Verify Upload Receipts & Hashes]
    V1 --> V2{All Uploads Confirmed?}
    V2 -->|No| V3[Retry Failed Uploads] --> V1
    V2 -->|Yes| V4[Update Data Provenance / Audit Log]
    V4 --> V5[Archive Source Package]
    V5 --> V6[Notify Downstream Consumers]
    V6 --> End(((End)))
